MHL2 series pneumatic gripper is wide opening parallel finger gripper, which is suitable for large objects. MHL air grippers are designed for applications that require a wide travel range of gripper fingers. It is ideal for gripping many different sized parts. Finger motion is synchronized by a rack-and-pinion mechanism. The double piston construction creates a compact gripper with large holding force. Auto switches can be integrally mounted.
Action: double acting
Applicable bore size: 10, 16, 20, 25, 32, 40 mm
Opening/closing stroke range: 20-200 mm
